Safety Basic Monitor
AS-i Diagnostics
Bit-field for devices that changed during the last step.
These numbers indicate the position of the bits that correspond to a certain de-
vice.
0: device not changed during the last step
1: device changed during the last step
Bit field coding for devices which are present:
The numbers indicate the position of the bit for the corresponding device.
0: Device is not present
1: Device is present
Byte
2
7
2
6
2
5
2
4
2
3
2
2
2
1
2
0
1 7 6 5 4 3 2 1 0
2 15 14 13 12 11 10 9 8
… …
32 255 254 253 252 251 250 249 248
Tab. 6-29.
Byte
2
7
2
6
2
5
2
4
2
3
2
2
2
1
2
0
1 7 6 5 4 3 2 1 0
2 15 14 13 12 11 10 9 8
… …
32 255 254 253 252 251 250 249 248
Tab. 6-30.
Coding of states and colors
Code
Bit [2 … 0]
status bzw. color
0
green permanent lighting
1
green flashing
2
yellow permanent lighting
3
yellow flashing
4
red permanent lighting
5
red flashing
6
grey or off
7
non existent
Bit 3 0: Device is not present in this OSSD
1: Device is present in this OSSD
Tab. 6-31.
