Safety Basic Monitor
AS-i Diagnostics
6.4.2.2 Transparent output data
The transparent output data are available there to the safe unit as non-safe addi-
tional bits, for example for Start buttons. They are linked with the input bits of the
input configured as non-safe terminals.
Ch 2 15
2
14
2
13
2
12
2
11
2
10
2
9
2
8
2
7
2
6
2
5
2
4
2
3
2
2
2
1
2
0
0 reserved S8 S7 S6 S5 S4 S3 S2 S1
Tab. 6-21.
