Safety Basic Monitor
AS-i Diagnostics
6.2 Diagnostics mode "Consortial monitor, for replacement"
Consortial diagnostics, with S-7-3 diagnostics added.
Information!
Diagnostics type: compatibility mode for Safety Basic Monitors starting with the Safety-
Version ’SV4.3’.
Address Meanining
basic address Consortial diagnostics, limited to 48 devices
simulated slave 1 status OSSD 1 and OSSD 2
simulated slave 2 S-7.F slave, input data = 0
simulated slave 3
Tab. 6-8.
Simulated slave 1: status OSSD 1 and OSSD 2 (binary data)
Data bit content
D0 status relay output 1
D1 status message output 1
D2 status relay output 2
D3 status message output 2
Tab. 6-9.
