Safety Basic Monitor
AS-i Diagnostics
6.4.3.5 Vendor specific object 11 … 38
Objects 11 … 38 correspond to Objects 7 … 10, but do not refer to the following
release circuits. The table shows the relationship:
OSSD device
colors
device colors with
device index
device col-
ors at switch
off
device colors at
switch off mit
device index
Vorverarb. object 3 object 4 - -
1 object 7 object 8 object 9 object 10
2 object 11 object 12 object 13 object 14
3 object 15 object 16 object 17 object 18
4 object 19 object 20 object 21 object 22
5 object 23 object 24 object 25 object 26
6 object 27 object 28 object 29 object 30
7 object 31 object 32 object 33 object 34
8 object 35 object 36 object 37 object 38
9 object 39 object 40 object 41 object 42
10 object 43 object 44 object 45 object 46
11 object 47 object 48 object 49 object 50
12 object 51 object 52 object 53 object 54
13 object 55 object 56 object 57 object 58
14 object 59 object 60 object 61 object 62
15 object 63 object 64 object 65 object 66
16 object 67 object 68 object 69 object 70
Tab. 6-36.
