14

Configuration and User Manual

Configuration and Theme Files

Configuration and theme files are stored and recalled locally from the Touchscreen. Each

configuration and theme that will be used on the Touchscreen must be loaded once during

setup or when the configuration or theme is modified.

When a Handheld Touchscreen is connected to the system and it does not have the

associated configuration and theme file for recall, the Touchscreen will prompt to begin

downloading the associated files. When connected wirelessly it is recommended that you

manually load the configuration files using removable media instead. File transfer over a

wireless connection can be slow.

Retrieve the Configuration and Theme Files

Configuration and theme files are available from the Paradigm Architectural Control

Processor (P-ACP) or from within the LightDesigner configuration.

Retrieve from the P-ACP

Step 1:

Insert removable media into the Paradigm Architectural Control Processor, either

USB or SD media.

Step 2:

Navigate to File Operations from the main menu.

Step 3:

Select Save LCD Files.

Step 4:

Select the desired configuration file from the available configurations in the list.

Step 5:

Select the media type for the save operation. Two files types will be exported; the

configuration file saves with a “*.lcdconf” extension and the theme saves with an

“*.lcdtheme” extension.

Retrieve from LightDesigner

Step 1:

From the LightDesigner configuration, select “Extract Portable Touchscreen

Files” from the (Project) menu. The Extract Portable Touchscreen Files dialog

displays.

Step 2:

Select which Portable Touchscreen files will be exported from the selection and

click [OK]. The Browse For Folder dialog displays for selection of a location the

files will be exported to, such as a removable USB device. Two files types will be

exported; the configuration file saves with a “*.lcdconf” extension and the theme

saves with an “*.lcdtheme” extension.

Loading Files to the Touchscreen

Step 1:

Insert the removable media into the appropriate location, SD or USB.

USB media is located on the bottom left edge of the Handheld.

SD media port is located behind the

Access Panel

.

Step 2:

Access the Setup menu by pressing the [Setup] button on the display or by

pressing the Mode button (

page 5

) located behind the

Access Panel

. The display

changes to the “About” tab of the Setup menu.

Step 3:

Press the [Files] button. A keypad displays for passcode entry.

Step 4:

Enter the four digit setup or admin passcode _ _ _ _ to access the “Files” menu.

By factory default, this setup passcode is 3031.

Step 5:

Press the [Config] button to load the configuration file(s) or press [Theme] to

load theme file(s) to the Touchscreen.
