DFX-8 Series Ultrasonic Flaw Detectors
73
Setting TCG Parameters
Activating TCG
1) Press the MENU key once to activate the menu items tab. Press the MENU
key multiple times to tab right, and the ESC key multiple times to tab left,
until the TCG menu is highlighted and displaying the submenu items.
Alternatively, press the LEFT and RIGHT arrow keys multiple times
using the left button wheel.
2) Use the UP and DOWN arrow keys multiple times on the left button
wheel to scroll through the sub menu items until TCG is highlighted.
3) Press the LEFT and RIGHT arrow keys on the right button wheel to
toggle the TCG feature ON. The menu items should now become active
and adjustable, as illustrated above.
Enter % Screen Height
1) Press the UP and DOWN arrow keys multiple times on the left button
wheel until % SCRN HEIGHT is highlighted, followed by pressing the
LEFT and RIGHT arrow keys on the right button wheel to scroll the value.
When the correct height is displayed, proceed to the next setting.
2) Alternatively, press the ENTER key to display the Digits Edit Box.
