DFX-8 Series Ultrasonic Flaw Detectors
57
3) Press the UP and DOWN arrow keys multiple times on the left button
wheel to scroll the highlighted value.
4) Press the LEFT and RIGHT arrow keys multiple times using the left
button wheel to scroll the digit locations.
5) Repeat steps 3 & 4 until the thickness is correctly displayed.
6) Press the OK key to set the THICKNESS and return to the menu screen, or
ESC to cancel entering the THICKNESS.
Note: Thickness is used to calculate the depth.
Transducer Angle
1) Press the UP and DOWN arrow keys multiple times on the left button
wheel until ANGLE is highlighted, followed by pressing the LEFT and
RIGHT arrow keys multiple times using the left button wheel to scroll the
value. When the correct angle is displayed, proceed to the next setting.
2) Alternatively, press the ENTER key to display the Digits Edit Box.
3) Press the UP and DOWN arrow keys multiple times on the left button
wheel to scroll the highlighted value.
4) Press the LEFT and RIGHT arrow keys multiple times using the left
button wheel to scroll the digit locations.
5) Repeat steps 3 & 4 until the angle is correctly displayed.
6) Press the OK key to set the ANGLE and return to the menu screen, or ESC
to cancel entering the ANGLE.
X-Offset
1) Press the UP and DOWN arrow keys multiple times on the left button
wheel until X-OFFSET is highlighted, followed by pressing the LEFT
