Dakota Ultrasonics
120
Note: At any point during a PEAK scan the operator may opt to clear the wave
drawing and start over.
1) Press the CLEAR key at any time to clear the currently displayed waveform,
and continue the scanning process.
Disabling PEAK
1) Press the PEAK key at any time to disable the feature.
Note: The PEAK key is also used in conjunction with the COMPARE feature.
When the compare feature is enabled, it takes control over the normal PEAK
functionality.
11.26 Freeze Waveform
The DFX-8 also includes a FREEZE mode that allows an operator the ability to
freeze a the current waveform being display on the screen at anytime. Once the
operator freezes the waveform, the transducer can be removed from the test
material. The following procure outlines the steps to activate and use the FREEZE
feature:
Activating Freeze
Note: Assuming the operator currently has a waveform on the display that
they’d like to freeze and have a closer look.
1) Press the FREEZE key located in the upper left corner of the keypad to
activate the feature.
2) Press the FREEZE key again at any time to toggle this feature OFF.
