DFX-8 Series Ultrasonic Flaw Detectors
43
3) Press the UP and DOWN arrow keys multiple times on the left button
wheel to scroll the highlighted value.
4) Press the LEFT and RIGHT arrow keys multiple times using the left
button wheel to scroll the digit locations.
5) Repeat steps 3 & 4 until the desired GATE1 value is displayed.
Note: In our example, a value less than 1 inch should be selected.
6) Press the OK key to set the value and return to the GT1 menu.
Gate1 Width
1) Use the UP and DOWN arrow keys multiple times on the left button
wheel to scroll through the sub menu items until GATE1 WIDTH is
highlighted.
2) Press the ENTER key to display the Digits Edit Box.
3) Press the UP and DOWN arrow keys multiple times on the left button
wheel to scroll the highlighted value.
4) Press the LEFT and RIGHT arrow keys multiple times using the left
button wheel to scroll the digit locations.
5) Repeat steps 3 & 4 until the desired GATE1 WIDTH value is displayed.
Note: In our example, a value greater than 1 inch should be selected.
6) Press the OK key to set the value and return to the GT1 menu.
Threshold Level
1) Use the UP and DOWN arrow keys multiple times on the left button
wheel to scroll through the sub menu items until THRESHOLD1 is
highlighted.
