Dakota Ultrasonics
102
Alternatively, press the LEFT and RIGHT arrow keys multiple times
using the left button wheel.
2) Use the UP and DOWN arrow keys multiple times on the left button
wheel to scroll through the sub menu items until RECT WAVE is highlighted.
3) Use the LEFT and RIGHT arrow keys on the right button wheel to scroll
the RECT WAVE options.
4) Once the RECT WAVE is displayed, press the MEAS key to return to the
measurement screen.
11.12 Detect Mark
Another look and feel option of the DFX-8 is the DETECT MARK feature. The detect
mark give the user the option to select: none, line, dots, or box. Depending on the
select made, an indication will be displayed on the waveform, showing where the
detection is occurring. It should be noted that the “box” option will only be visible in
RF view. The following screenshots illustrate the above selection options:
