SECTION 3 - CHASSIS & TURNTABLE
3-18 – JLG Lift – 3120788
15. Oil all exposed surfaces inside the hub (1G). Place
thrust washer (11) into the counterbore in top of the
carrier.
BEWARE OF SHARP EDGES IN THE COUNTERBORE WHEN YOU
INSTALL THE O-RING.
16. Set the cover (6A) on table, interior side up. Grease
o-ring (5) and place it into the counterbore around
the edge of cover (6A).
NOTE: The o-ring may be stretched or pinched together to
make it fit the counterbore exactly.
17. Place cover sub-assembly (6) onto ring gear (4),
aligning the pipe plug holes according to the align-
ment prior to disassembly.
18. Place four flatwashers (16) on top of the bolt holes in
the cover sub-assembly.
