SECTION 1 - SPECIFICATIONS
3120788 – JLG Lift – 1-3
1.4 SPECIFICATIONS AND PERFORMANCE
DATA
Table 1-9. Specifications and Performance Data - 400S
Maximum Work Load (Capacity):
Unrestricted:
Restricted:
Optional: standard
500 lbs. (230 kg.)
1000 lbs. (230 kg)
750 lbs. (340 kg)
Maximum Travel Grade, Stowed Position
(Gradeability) 2 W/D-30%
4 W/D-45%
Maximum Travel Grade, Stowed Position
(Side Slope)
5 o
Maximum Vertical Platform Height: 40 ft. (12 m)
Maximum Horizontal Platform Reach: 34 ft. (10 m.)
Turning Radius (Outside) 16 ft. (5 m.)
Turning Radius (Inside) 6 ft.-8 in. (2 m.)
Overall Width 6ft.- 6in. (1.98 m)
Tail swing Zero
Stowed Height 7ft. 4in. (2.24 m)
Stowed Length 20ft. 2in. (6.15 m)
Wheelbase 7ft. 10in. (2,3 m)
Ground Clearance 12in. (30 cm)
Max. Tire Load (400S-500 lbs. Cap.)
Max. Tire Load (400S-750 lbs. Cap.) 8200 lbs. (3720 kg)
7200 lbs. (3266 kg)
Ground Bearing Pressure
12x16.5 FF Tires
14x17.5 pneumatic tires
58 psi (4.07 kg/cm 2 )
45 psi (3.16 kg/cm 2 )
Travel Speed, boom stowed.(2WD/4WD) 4.5 m.p.h. (7.24 kmh)
(27-32 sec/ 200ft.)
Travel Speed, boom elevated. (2WD/4WD) 0.75 m.p.h. (1.20 kmh)
(46-115 sec/ 50 ft.)
Gross Machine Weight Std. 2wd Machine
(Platform Empty, Pneumatic Tires)
500 lb. (230 kg) Capacity
750 lb. (340 kg) Capacity
12,525 lbs. (5681kg)
13,525 lbs. (6135 kg)
Maximum System Voltage 12 VDC
Max. Hydraulic System Operating Pressure 4060 psi (280 bar)
Manual Force 400 N maximum
Maximum Wind Speed 28 mph (12.5 m/s)
Table 1-10. Specifications and Performance Data - 460SJ
Maximum Work Load (Capacity):
Unrestricted:
500 lbs. (230 kg.)
Maximum Travel Grade, Stowed Position
(Gradeability) 2 W/D - 30%
4 W/D - 45%
Maximum Travel Grade, Stowed Position
(Side Slope)
5 o
Maximum Vertical Platform Height: 46 ft. (14 m.)
Maximum Horizontal Platform Reach: 40 ft. (12 m.)
Turning Radius (Outside) 16 ft. (5 m.)
Turning Radius (Inside) 6 ft.-8 in. (2 m.)
Overall Width 6ft.- 6in. (1.98 m)
Tail swing Zero
Stowed Height 7ft. 4in. (2.24 m)
Stowed Length 20ft. 2in. (6.15 m)
Wheelbase 7ft. 10in. (2,3 m)
Ground Clearance 12in. (30 cm)
Max. Tire Load 8350 lbs. (3788 kg)
Ground Bearing Pressure
58 psi (4.07 kg/cm 2 )
Travel Speed, boom stowed.(2WD/4WD) 4.5 m.p.h. (7.24 kmh)
(27-32 sec/ 200ft.)
Travel Speed, boom elevated. (2WD/
4WD) 0.75 m.p.h. (1.20 kmh)
(46-115 sec/ 50 ft.)
Gross Machine Weight Std. 2wd Machine
(Platform Empty, Pneumatic Tires) 15,855 lb. (7192 kg)
Maximum System Voltage 12 VDC
Max. Hydraulic System Operating Pres-
sure 4060 psi (280 bar)
Maximum Manual Force 400 N
Maximum Wind Speed 28 mph (12.5 m/s)
