SECTION 6 - JLG CONTROL SYSTEM (S/N 61718 TO PRESENT)
6-42 – JLG Lift – 3120788
REAR LEFT WHEEL BLOCKED The wheel is not responding to steer commands. Fault clears when condition
clears.
REAR RIGHT WHEEL BLOCKED The wheel is not responding to steer commands. Fault clears when condition
clears.
FRONT LEFT WHEEL SENSOR OUT
OF RANGE LOW A short to ground or open circuit has been detected on the steering angle sen-
sor.
FRONT LEFT WHEEL SENSOR OUT
OF RANGE HIGH A short to battery has been detected on the steering angle sensor.
FRONT RIGHT WHEEL SENSOR OUT
OF RANGE LOW A short to ground or open circuit has been detected on the steering angle sen-
sor.
FRONT RIGHT WHEEL SENSOR OUT
OF RANGE HIGH A short to battery has been detected on the steering angle sensor.
REAR LEFT WHEEL SENSOR OUT OF
RANGE LOW A short to ground or open circuit has been detected on the steering angle sen-
sor.
REAR LEFT WHEEL SENSOR OUT OF
RANGE HIGH A short to battery has been detected on the steering angle sensor.
REAR RIGHT WHEEL SENSOR OUT
OF RANGE LOW A short to ground or open circuit has been detected on the steering angle sen-
sor.
REAR RIGHT WHEEL SENSOR OUT
OF RANGE HIGH A short to battery has been detected on the steering angle sensor.
8/7 Flash code 8/7 indicates new main angle sensors 10
NEW MAIN ANGL1 SENSOR
DETECTED The system detected a different main angle #1 sensor than it was calibrated
with. (1250AJP only.)
NEW MAIN ANGL2 SENSOR
DETECTED The system detected a different main angle #2 sensor than it was calibrated
with. (1250AJP only.)
Table 6-3. Help Fault Codes, Displayed Faults, and Descriptions - S/N 66995 to Present
Fault Flash
Code
Communicated (Displayed on
Analyzer) Fault
Description Priority
