SECTION 6 - JLG CONTROL SYSTEM (S/N 61718 TO PRESENT)
6-24 – JLG Lift – 3120788
Table 6-3. Help Fault Codes, Displayed Faults, and Descriptions - S/N 66995 to Present
Fault Flash
Code
Communicated (Displayed on
Analyzer) Fault
Description Priority
None No flash code is indicated for the following help messages. They are intended
to hint at a possible problem if the vehicle is not behaving as expected.
1
EVERYTHING OK The “normal” help message in platform mode
GROUND MODE OK The “normal” help message in ground mode
FSW OPEN A drive or boom function has been selected but footswitch is open.
RUNNING AT CREEP — CREEP
SWITCH OPEN All function speeds are limited to creep because the creep switch is open.
RUNNING AT CREEP — TILTED AND
ABOVE ELEVATION All boom function speeds are limited to creep because the vehicle is tilted and
above elevation.
RUNNING AT CUTBACK — OUT OF
TRANSPORT POSITION Drive speed is limited to “ELEVATED MAX” because the vehicle is out of trans-
port position.
CHASSIS TILT SENSOR OUT OF
RANGE The chassis tilt sensor has indicated a tilt angle greater than 19 degrees for
more than 4 seconds. Not reported during 2 second power-up.
LOAD SENSOR READING UNDER
WEIGHT The load sensor is reading 20% or more under the calibrated zero point. This
fault may occur if the basket is resting on the ground. Not reported during 2 sec-
ond power-up.
ENVELOPE ENCROACHED —
HYDRAULICS SUSPENDED Only occurs on machines with envelope control. The system has detected an
envelope violation
OVER MOMENT — HYDRAULICS SUS-
PENDED Only occurs on machines with moment control. The system has detected an
over moment violation.
UNDER MOMENT — HYDRAULICS
SUSPENDED Only occurs on machines with moment control. The system has detected an
under moment violation.
1/1 Flash code 1/1 indicates a “sleep” mode.
NOT REQUIRED
2/1 Flash code 2/1 indicates problems with footswitch. 2
FSW FAULTY The two footswitch inputs have read the same state for more than one second.
An EMS cycle is required.
KEYSWITCH FAULTY Both platform and ground modes are selected simultaneously
