SECTION 6 - JLG CONTROL SYSTEM (S/N 61718 TO PRESENT)
6-30 – JLG Lift – 3120788
JIB DOWN OPEN CIRCUIT
JIB DOWN SHORT TO BATTERY
JIB LEFT SHORT TO GROUND
JIB LEFT OPEN CIRCUIT
JIB LEFT SHORT TO BATTERY
JIB RIGHT SHORT TO GROUND
JIB RIGHT OPEN CIRCUIT
JIB RIGHT SHORT TO BATTERY
TOWER UP SHORT TO GROUND
TOWER UP OPEN CIRCUIT
TOWER UP SHORT TO BATTERY
TOWER DOWN SHORT TO GROUND
TOWER DOWN OPEN CIRCUIT
TOWER DOWN SHORT TO BATTERY
TOWER IN SHORT TO GROUND
TOWER IN OPEN CIRCUIT
TOWER IN SHORT TO BATTERY
TOWER OUT SHORT TO GROUND
TOWER OUT OPEN CIRCUIT
TOWER OUT SHORT TO BATTERY
MAIN IN SHORT TO GROUND
MAIN IN OPEN CIRCUIT
MAIN IN SHORT TO BATTERY
MAIN OUT SHORT TO GROUND
MAIN OUT OPEN CIRCUIT
MAIN OUT SHORT TO BATTERY
LIFT UP DUMP SHORT TO GROUND
LIFT UP DUMP OPEN CIRCUIT
LIFT UP DUMP SHORT TO BATTERY
LIFT DOWN HOLDING SHORT TO
GROUND
LIFT DOWN HOLDING OPEN CIRCUIT
LIFT DOWN HOLDING SHORT TO
BATTERY
LIFT PILOT VALVE SHORT TO
GROUND Only occurs on machines with gravity lift down.
LIFT PILOT VALVE SHORT TO BAT-
TERY Only occurs on machines with gravity lift down.
LIFT PILOT VALVE OPEN CIRCUIT Only occurs on machines with gravity lift down.
LIFT DOWN AUX VALVE SHORT TO
GROUND Only occurs on machines with gravity lift down.
LIFT DOWN AUX VALVE SHORT TO
BATTERY Only occurs on machines with gravity lift down.
Table 6-3. Help Fault Codes, Displayed Faults, and Descriptions - S/N 66995 to Present
Fault Flash
Code
Communicated (Displayed on
Analyzer) Fault
Description Priority
