SECTION 1 - SPECIFICATIONS
3120788 – JLG Lift – 1-1
SECTION 1. SPECIFICATIONS
1.1 CAPACITIES
1.2 ENGINE SPECIFICATIONS
NOTE: RPM Tolerances are ± 100.
Table 1-1. Capacities
Fuel Tank 26 gallons (98.4 liters)
Hydraulic Tank 40.0 gallons (152 liters)
Hydraulic System (Including Tank) 52 gallons (196.8 liters)
Drive Hub 17 ounces (0.5 liters)
Engine Oil Capacity
Ford
Deutz
Caterpillar
GM
4.5 Quarts (4.25 L) w/Filter
6.3 qts. (6 L) w/Filter
3.8 quarts (3.6 L) crankcase only
4.5 qts. (4.25 L) w/Filter
Table 1-2. Ford LRG-425 (Gas or Dual Fuel)
Type 4 cylinder, 4 stroke, spark
ignition
Fuel Gasoline or Gasoline/LP Gas
Bore 3 in. (96 mm)
Stroke 3.4 in. (86.4 mm)
Displacement 153 cu. in. (2.5 L)
Firing Order 1-3-4-2
BHP at Max. RPM 82
Oil Capacity 4.5 quarts (4.26 L)
Low RPM 1000
Mid RPM 1800
High RPM 3000
Fuel Consumption: Gasoline
Intermittent
Continuous
6 gal. hr.
5 gal. hr.
Fuel Consumption: LPG
Intermittent
Continuous
26 lbs. hr.
23 lbs. hr.
Spark Plug AWSF-52-C
Spark Plug Gap 0.044 in. (1.117 mm)
Table 1-3. Deutz F3M1011F/F3M2011F
Fuel Diesel
No. of Cylinders 3
Bore 3.6 in. (91 mm)
Stroke 4.4 in. (112 mm)
Displacement 133 cu. in. (2184 cm³)
BHP at Max. RPM 48
Oil Capacity
crankcase
cooler
total capacity
6.3 quarts (6 L)
4.75 quarts (4.5 L)
11 quarts (10.5 L)
Low RPM 1200
Mid RPM 1800
High RPM 2800
Table 1-4. Isuzu 4LE1
Fuel Diesel
No. of Cylinders 4
BHP at Max. RPM 45
Low RPM 1000
Mid RPM 1500
High RPM 2800
Table 1-5. Caterpillar 3024/C2.2
Fuel Diesel
No. of Cylinders 4
BHP 46.5 hp (34 kW)
Bore 3.307 in. (84 mm)
Stroke 3.9370 in. (112 mm)
Displacement 134.3 cu. in. (2.2L)
Oil Capacity w/filter 10 qt. (9.4 L)
Compression Ratio 19:1
Firing Order 1-3-4-2
Max. RPM 2800
