Fault/Diagnostic Trouble Code Interaction
All fault and diagnostic information is managed through
the Faults page. Interaction includes viewing fault mes-
sages, downloading fault data (fault snapshot and flight
data recorder), erasing faults from memory, and defining
variables for fault data logging.
Faults are separated into two categories, Active and His-
toric. Active faults are active in real-time and historic faults
have been generated at some instance in time that may or
may not be active in real-time. Once a fault has become
active, it is immediately logged as historic and a snapshot
and flight data log is saved. Figure 3-86. shows an exam-
ple of the fault page when an active fault has been gener-
ated. Notice that the fault is present in both the active and
historic lists and the malfunction indicator lamp (MIL) has
been illuminated. Figure 3-87. shows an example of the
fault page with a historic fault stored in memory.
Figure 3-86. Faults Page with Active Fault Message
Base Fault snapshot
variable definitions
(CAN NOT be altered)
Custom Fault Snapshot
variable definitions (User
Defined)
Base Flight Data
Recorder variable
definitions (CAN
NOT be altered)
Custom Flight Data
Recorder variable
definitions (User Defined)
