TravelMate 4000M Standard VGA Video Modes
Mode
(hex)
Type
Colors
(1)
Columns Rows Buffer
Char.
Size (2)
Res. (3)
1 text 16/256 KB 40 25 B8000 9
Ч
16 360
Ч
400
2 text 16/256 KB 80 25 B8000 9
Ч
16 720
Ч
400
3 text 16/256 KB 80 25 B8000 9
Ч
16 720
Ч
400
4 graph. 4/256 KB 40 25 B8000 8
Ч
8 320
Ч
200
5 graph. 4/256 KB 40 25 B8000 8
Ч
8 320
Ч
200
6 graph. 2/256 KB 80 25 B8000 8
Ч
8 640
Ч
200
7 text 4 Mono 80 25 B0000 9
Ч
16 720
Ч
400
D graph. 16/256 KB 40 25 A0000 8
Ч
8 320
Ч
200
E graph. 16/256 KB 80 25 A0000 8
Ч
8 640
Ч
200
F graph. 4 Mono 80 25 A0000 8
Ч
14 640
Ч
350
10 graph. 16/256 KB 80 25 A0000 8
Ч
14 640
Ч
350
11 graph. 2/256 KB 80 30 A0000 8
Ч
16 640
Ч
480
12 graph. 16/256 KB 80 30 A0000 8
Ч
16 640
Ч
480
13 graph. 256/256 KB 40 25 A0000 8
Ч
8 320
Ч
200
Notes to the table:
Default modes are 3 for color monitors and 7+ for monochrome monitors.
(1) Colors: Where two numbers are given, the first is the number of colors available at one
time; the second number is the total number of possible colors.
(2) Character Size: The size of the matrix that contains each text character.
(3) Resolution: All 200-line modes are “double-scanned” to display 400 lines on screen.
Advanced Monitor Operations
8-14 VGA External Monitor Utilities
