Chapter 4. Example Operations
61200.076L2-1 TSU 600 User Manual
87
Step 2. Configure DTE Port (1.1 - Nx56/64) (From Option
Module)
Table 4-B provides configuration information for DTE
ports.
Table 4-B
Configuration for DTE Port
MENU ITEM SELECTION USED SELECTIONS AVAILABLE
1)INTERFACE V.35 V.35, RS530
2)RATE 56/64 56K 56K, 64K
3)TX CLK CNTRL INTERNAL INTERNAL, INTERNAL & INVERTED,
EXTERNAL
4)DATA NORM NORMAL, INVERT
5)CTS FORCED ON NORMAL, FORCE ON
6)DCD FORCED ON NORMAL, FORCE ON
7)DSR FORCED ON NORMAL, FORCE ON
8)"O" INHIB ON ON, OFF
Step 3. Select the number of DS0s/Port:_____12___
The number of DS0s/Port is based on the Data Rate
Table in the appendix, Configure DTE Port:
