Chapter 4. Example Operations
86
TSU 600 User Manual 61200.076L2-1
STEPS TO SET UP VOICE AND DATA MIX
The five steps required to set up voice and data mix
are presented in this section along with tables that
provide examples of the required information.
Prior to Step 1
Complete the configuration chart. The configuration
charts from the appendix, System Configuration Charts,
can be copied and filled out to use as a reference or
guide prior to actually setting any configuration.
Step 1. Configure the Network
Table 4-A provides configuration information for the
network interface.
Table 4-A
Configuration for Network Interface
MENU ITEM SELECTION USED SELECTIONS AVAILABLE
1)FORMAT ESF D4, ESF
2)CODE AMI AMI, B8ZS
3)YEL ALARM ENA ENA, DIS
4)XMIT PRM OFF ON, OFF
5)TIMING MODE NETWORK NETWORK (NI), INTERNAL,
DTE-BASE, NORMAL (CSU)
6)INBAND LOOPBK ACCEPT ACCEPT, REJECT
7)LINE BUILD OUT 0 dB 0 dB; -7.5 dB; -15 dB; -22 dB; AUTO
8)BIT STUFFING DISABLE DISABLE, ENABLE
