Chapter 4. Example Operations
61200.076L2-1 TSU 600 User Manual
95
TEMPORARY MAP
The TSU 600 is now holding the newly created DS0
Map A in a file as a temporary map. It can be re-
viewed or edited through the DS0 Map A menu.
Review
To Review the Temporary file, follow standard operat-
ing procedures to access the first two submenu items
of 5)DS0 MAP A (see Figure 4-9).
Figure 4-9
First Screen for Choosing to Review Temporary Files
Throughout this review example, it is assumed that DS0 17
was inadvertently skipped.
Upon activating the 5)DS0 Map A menu, the fourth
submenu item must be accessed. Select Review Temp
by pressing number 4 or using the scroll to place the
cursor on 4)REVIEW TEMP. Press Enter to activate
the Review function. The unit begins the display with
the number of DS0s set for Idle (see Figure 4-10).
Figure 4-10
A Review Screen
