Chapter 3. Operation
58 TSU 600 User Manual 61200.076L2-1
CONFIGURATION (CONFIG)
The Configuration menu is used to set the TSU 600
operational configuration, including all network
interface parameters and the allocation of the DS0s
and the port parameters. See Figure 3-12.
1) NETWORK (NI)
1) FORMAT
2) CODE
3) YEL ALARM
4) XMIT PRM
5) TIMING MODE
6) SET LBO
7) INBAND LPBCK
8) BIT STUFFING
2) UNIT
3) ACCESS
4) INIT MODEM
5) EXIT TERM MODE
2)CONFIG
3) MAP EXCHANGE
7) PORT CONFIG
1) COPY A > TEMP
2) CREATE TEMP
3) REVIEW MAP A
4)REVIEW TEMP
5) EDIT TEMP
6) APPLY TEMP >A
0.1 Nx56/64
(OPTION PORTS)
5) DS0 MAP A
1) INTFACE
2) RATE (56/64)
3) TX CLK CNTRL
4) DATA
5) CTS
6) DCD
7) DSR
8) "0" INHIB
6) DS0 MAP B
1) COPY B > TEMP
2) CREATE TEMP
3) REVIEW MAP B
4)REVIEW TEMP
5) EDIT TEMP
6) APPLY TEMP > B
1) MAP A @:HH:MM
2) MAP B @:HH:MM
4) MAP IN USE: A (B)
OFF
AUTO
2) TRAPS
1) CNTRL PORT
Figure 3-12
Complete Configuration Menu
Menu flow is normally depicted from left to right.
Arrows on the lower right of the screen indicate the
direction of scrolling to use to view additional menu
items. At every level of the menu pressing Cancel
returns the system to the previous menu level. Press-
ing Cancel repeatedly returns the system to the Main
menu.
