TEST
The Test menu is used to initiate different types of
tests of the unit and to view test results. Test results
are displayed in the LCD window. The Test menu
contains four items (see Figure 3-20).
The execution of tests will disrupt some of the normal
operation. See individual menu items concerning tests
before executing.
4) TEST
2) RUN SELFTEST
(Displays Results)
1) LOCAL LOOPBK
2) REMOTE LOOPBK
(OPTION PORT)
1) NETWORK TESTS
3) PORT TEST
LINE ON
PAYLOAD ON
NO LOOPBACK
QRSS ALL DS0s
QRSS TST DS0s
NONE
ATT INBAND LLB
ANSI FDL LLB
ANSI FDL PLB
NO LOOPBACK
3) PATTERN
4) CANCEL TEST
4) PATTERN RESULT (Displays Results)
ALL ONES
ALL ZEROS
Figure 3-20
Complete Test Menu
Menu flow is normally depicted from left to right.
Arrows on the lower right of the screen indicate the
scrolling direction to view additional menu items. At
every level of the menu pressing Cancel returns the
system to the previous menu level. Pressing Cancel
repeatedly returns the system to the Main menu.
