Chapter 4. Example Operations
92
TSU 600 User Manual 61200.076L2-1
CONFIGURING THE DS0 MAP
From the first menu position scroll down or use
number 5 to select the DS0 MAP A configuration.
Press number 5 again or Enter to enter the DS0 MAP A
Configuration menu (see Figure 4-5).
Figure 4-5
DS0 Map A and Map B Configuration Menu Items
Scroll down or press number 2 to place the cursor on
2)CREATE TEMP menu item. Press Enter to activate
the Create Map menu which opens a display from
which a DS0 number can be selected (see Figure 4-6).
Figure 4-6
Create Map Menu with Displayed DS0 Number
If the DS0 number displayed is the desired number,
press Enter to select it for an entry.
Display the correct numbers by entering numbers or
by scrolling. Press Enter to record the displayed DS0
for an entry and advance the cursor to the Passthru
selection field.
