Chapter 1. Introduction
24 TSU 600 User Manual 61200.076L2-1
Corporate
TSU 600 supports LAN bridge with base Nx. The PBX
system uses the DSX-1 module. The plug-on V.35 is
used to interface to the video telecom equipment. See
Figure 1-16.
T-Watch Management Software
The T-Watch software runs under Microsoft Windows
allowing full access to local and remote TSU units.
Test, monitor, and performance information is avail-
able with pull down menus. It is possible to dial into
the system with a modem or to access remote units via
the FDL. See Figure 1-16.
TSU 100
Bridge
Plug on V.35
BASE V.35 or
EIA 530 DTE
interface
Regional Sales Office
BASE V.35 or
EIA 530 DTE
interface
DSX-1 Module
Branch Office
BASE V.35 or
EIA 530 DTE
interface
Bridge
Plug on V.35
Corporate Office
DSX-1 Module
"T-Watch"
Management
Software
T1 FT1
T1
Inter Exchange
Carrier
KEY System
Corporate PBX
DSX-1
Module
Figure 1-16
Variations of Mixed Applications
