Appendix C. System Configuration Charts
61200.076L2-1 TSU 600 User Manual
113
Step 4: DS0 Map A Configuration
Table C-C
DS0 Map A Configuration
DSO # ASSIGN TO PASSTHRU? DSO # ASSIGN TO PASSTHRU?
1 13
2 14
3 15
4 16
5 17
6 18
7 19
8 20
9 21
10 22
11 23
12 24
Step 5: DS0 Map B Configuration
Table C-D
DS0 Map B Configuration
DSO # ASSIGN TO PASSTHRU? DSO # ASSIGN TO PASSTHRU?
1 13
2 14
3 15
4 16
5 17
6 18
7 19
8 20
9 21
10 22
11 23
12 24
