Appendix C. System Configuration Charts
112
TSU 600 User Manual 61200.076L2-1
Step 2: Configure DTE PORT: (1.1 Nx56/64)
Table C-B
Configuration Chart for DTE Port
MENU ITEM SELECTION USED SELECTIONS AVAILABLE
1) INTERFACE V.35*, RS530
2) RATE 56/64 56K, 64K*
3) TX CLK CNTRL INTERNAL*, INTERNAL &
INVERTED, EXTERNAL
4) DATA NORMAL*, INVERT
5) CTS NORMAL*, FORCE ON
6) DCD NORMAL*, FORCE ON
7) DSR NORMAL*, FORCE ON
8) "O" INHIB ON, OFF*
* = Factory Default
Step 3: Select number of DS0s/PORT __________________
Based on Data Rate Table in the appendix, DTE Data
Rate Chart.
