Chapter 2. Installation
30 TSU 600 User Manual 61200.076L2-1
WIRING
Network
On the rear panel the TSU 600 is an eight-position
modular jack labeled NETWORK. This connector is
used for connecting to the network. See Table 2-A for
the pinout for the network connector.
Connections
The network connections are as follows:
Connector type (USOC) RJ-48C
Part number AMP# 555164-2
Table 2-A
Network Pinout
PIN NAME DESCRIPTION
1 R1 RXDATA-RING Receive data from the network
2 T1 RXDATA-TIP Receive data from the network
3 UNUSED
4 R TXDATA-RING Send data toward the network
5 T TXDATA-TIP Send data toward the network
6,7,8 UNUSED
