VS18/VS26

MAINTENANCE & INSTRUCTION BOOKLET

8.5.2 Interbus-S

wiring

Line parameter

Parameter

Lütze (manufacturer)

Impedance in Ohms

158

Outer jacket

PVC

Core diameter (mm)

3*2*0.25

Outside diameter (mm)

8.6


Line lengths

Transmission rate in kBit/s

500

Main line between nodes

400m

Maximum length

13km


8.5.3 Interbus-S address and baud rate setting

The address of the valve island outputs are determined by the physical position in the Interbus
Network.

The baud rate is fixed at 500 kBit/s.

8.5.4 Interbus-S output addressing

Output addressing of the VS18/VS26 Interbus-S valve island varies with different PLC
manufacturers and due to the increasing number of compatible Interbus-S master controllers, it
would be impractical to create detailed instructions for the Norgren node’s output addressing on
a particular master.

8.5.5 Diagnostics

The VS18/VS26 Interbus-S slave can determine the state of the +24V for the valves and report
any errors to the Interbus-S master. If the valve power is not present the master will show at the
time of configuration that a peripheral fault has occurred.

VS2672926-KG00E_05/07 Page

72/97
