VS18/VS26

MAINTENANCE & INSTRUCTION BOOKLET

4.5.3 ISO

standard

ISO 15407-2 (size 26mm and 18mm)

4.5.4 Fieldbus

standards

Norgren Profibus DP Fieldbus systems conform to
DIN 19245 part 3.

Norgren DeviceNet systems conform to
DeviceNet specification volume 1 release 2 and the Pneumatic Valve Device Profile.

Norgren CANopen Fieldbus systems conform to
CANopen communication profile CiA DS-301 V4.0.

Norgren Interbus-S Fieldbus systems conform to
DIN 19258.

Norgren AS-Interface Fieldbus systems conform to
AS-I V2.11 specification.

For detailed information on Fieldbus protocols please refer to section

8

.


4.5.5 CNOMO

standard

The M23 19-pin connector fulfils CNOMO standard E03.62.530.N.

For more information on this standard please refer to the CNOMO website

www.cnomo.com

.

For more information on the M23 19-pin connector please refer to section

7.4

.


4.5.6 DIN

standard

Colour code of D-Sub connectors according DIN 47100

4.5.7 UL/CSA

approval

Investigated to UL 429 - 5th edition & CSA 22.2 No.139 - 1982 for 24V DC electrically operated
valves.

VS2672926-KG00E_05/07 Page

14/97
