background image

VS18/VS26

MAINTENANCE & INSTRUCTION BOOKLET

6.3 V

ARIANT WITH

NPTF1/2“

CONDUIT WITH FLYING LEADS

The single station sub-base with NPTF1/2“ conduit with flying leads is available with
G pneumatic ports only.

The power supply can be 24V DC or 115V AC. If you use 115V AC, connection of the protective
earth (PE) ground is required.

6.3.1 Wiring

information

Wire colour

Function

Green Earth
Yellow

Signal for solenoid 12

Black

Common for solenoid 12 and 14

Red

Signal for solenoid 14


VS2672926-KG00E_05/07 Page

36/97
