HID DTC4500e User Guide - Manual (Page 86)

DTC4500e_User Guide_EN, PLT-01669, Rev. 1.1
Page 86 April 2014
6.1.4 Printer-Specific Tools
The status icons are as follows:
This icon indicates that the print ribbon supply is low and will require replacement
soon. The entire ribbon cartridge must be replaced.
This icon indicates that the printer needs to be cleaned.
This icon is only displayed for printers with an attached dual-input card hopper and
indicates that the top input hopper is currently selected.
This icon is only displayed for printers with an attached dual-input card hopper and
indicates that the bottom input hopper is currently selected.
Press the button to scroll through the details of the printer and perform the action.
Press the button to select the option.
When is selected, use the left down arrow to scroll through the Info, Test Prints,
and Languages and Exit.
Use the corner arrow to run that option.
The curved arrow will return to the first screen.
