Setting Description
Head Home Offset This setting is a calibration driven value and should not be
adjusted. If the Printhead assembly is replaced then this value
may need to be adjusted.
Note: This is factory set and should not be changed unless
directed by a technician.
Head Print Offset This setting is a calibration driven value and should not be
adjusted. If the printhead assembly is replaced then this value
may need to be adjusted.
Note: This is factory set and should not be changed unless
directed by a technician.
Head Contact Offset This setting is a calibration driven value and should not be
adjusted. If the printhead assembly is replaced then this value
may need to be adjusted.
Note: This is factory set and should not be changed unless
directed by a technician.
Head Queue Offset This setting is a calibration driven value and should not be
adjusted. If the printhead assembly is replaced then this value
may need to be adjusted.
Note: This is factory set and should not be changed unless
directed by a technician..
Head Card Thickness
Offset
Adjusts the card handling path to allow for variances in card
thickness.
Head Smart Card Engage
Offset
Adjusts the position of the print head to allow smart card encoder
contact.
Head Mag Offset Adjusts the printhead for magnetic encoding.
Overlay Heat Adjust Adjusts the temperature setting for overlay film.
10 Mil Card Queue Offset Adjusts the input queue for use with thick cards.
Erase Speed Adjusts the speed of the erasure process.
Standard Resin Head
Adjust
Use this adjustment for Black standard resin text and barcodes if
they appear faded, too light or too dark.
Maximum Adjustment Range is +/- 100.
This control can be helpful for fine-tuning the transfer of resin text
and bar codes.
Printhead Smart Cue
Offset
Adjusts the card handling path to allow for variances in card
thickness.
