DTC4500e_User Guide_EN, PLT-01669, Rev. 1.1
April 2014 Page 15
Term Function
Operating Systems Windows® XP / Vista™ (32 bit & 64 bit) / Server 2003 & 2008 /
Windows® 7 (32 & 64 bit) / Windows® 8 (32 & 64 bit) / Linux®
Interface USB 2.0 and Ethernet with internal print server
Operating
Temperature
65 degrees to 80 degrees F / 18 degrees to 27 degrees C
Humidity 20-80% non-condensing
Weight Single-Sided: 8 lbs. / 3.63 Kg; Dual-Sided: 10 lbs. / 4.54 Kg
Agency Listings Safety: UL 60950-1, CSA C22.2 (60950-1), and CE; EMC; FCC Class
A, CRC c1374, CE (EN 55022 Class A, EN 55024), CCC, BSMI, KCC
Supply Voltage 100-240 VAC, 1.6 A
Supply Frequency 50 Hz / 60 Hz
Warranty Printer – Two years; Printhead – Two years, unlimited pass with
UltraCard™
Encoding Options
Supported
125kHz (HID Prox) reader
13.56 MHz (iCLASS, MIFARE, ISO 14443 A/B, ISO 15693) read/write
encoder
Contact Smart Card Encoder reads from and writes to all ISO7816
1/2/3/4 memory and microprocessor smart cards (T=0, T=1) as well as
synchronous cards.
ISO Magnetic Stripe Encoding, dual high- and low-coercivity, Tracks
1,2 and 3
Options Single Wire Ethernet and USB 2.0 Interface for inline printing and
encoding
Single wire Ethernet encoding is only available for iCLASS and Contact
Smart Card encoding)
Dual-Sided Printing Module – Upgradable
Dual Input Card Hopper
Same-Side Input / Output Card Hopper – Upgradable
Smart Card Encoding (contact / contactless) – Upgradable
Magnetic Stripe Encoding – Upgradable
Printer Cleaning Kit
