Management Menus
46
If an unrecognized type of TFTP request is received, the following message
appears:
The symbol > denotes the IP address of the requesting node in dotted
decimal notation.
EtherMeter
The EtherMeter option on the Administration menu modifies the
function of the port indicators on the current hub module’s front panel.
The indicators ordinarily display network activity on an indicator-per-port
basis. Activating the
EtherMeter option employs the indicators on a per-
hub or per-module basis. The indicators cooperatively show a cumulative
display of network activity, much like a graphic equalizer displays the
volume of sound at a certain frequency.
Diagnostics
The Administration menu’s Diagnostics option enables you to run a
limited set of diagnostic tests on the currently selected module’s
functionality. When you select this option, the management agent
performs diagnostic tests and displays the results similar to the following
display:
The top of the screen shows the user-configured hub name and selected
module name. Below that is the module’s model number (AT-TS24TR in
this example), the module’s MAC address, and the module’s firmware
version. It also indicates if a firmware cassette is installed.
Sunnyvale
TFTP request received from node >: Implied request ignored
Sunnyvale
Module 1 - Accounting A
Please select an option:
> Default LED display (per-port activity)
EtherMeter
Sunnyvale
Module 1—Accounting A
Allied Telesyn AT-TS24TR Stackable Hub 4.0
MAC Address 0000F4 78126D
AT-S10 Advanced TurboStack Hub Manager: 4.0
Firmware Cassette Installed
Running 8 hours, 42 minutes, 15 seconds
Diagnostic Results:
Flash PROM Good
Address PROM Good
RAM Good
Network Interface
Good
Serial Interface Good
MPR Chip Good
(hit Return to return to previous menu)
