Management Menus
30
To display module statistics per counter:
1.
Select a counter from the
Module Statistics
menu.
For example, enter T to see the
Total Frames
graph, similar to
the following:
2.
Press
Return
to go back to the
Module Statistics
menu.
Individual Port
Overview
This option requires you to enter a port number first, and then displays a
summary of the selected port’s activity.
For example, Port 3’s overview may be similar to the following:
Zero Counters
This option clears all of the statistics counters on the entire module to
zero.
Sunnyvale
Module 1—Accounting A
Total Frames
Port 1:Secondary port->13
0 |
Port 2:Room 1150
0 |
Port 3:Room 1151
2031 |
Port 4:
0 |
Port 5:
33414 |###
Port 6:
16707 |#
Port 7:
66828 |#######
Port 8:
0 |
Port 9:
50121 |####
Port 10:
0 |
Port 11:
16707 |#
Port 12:
33414 |###
Port 13:Primary port->1
116949 |#############
-----------------------
(hit Return to resume previous menu)
Sunnyvale
Module 1-Accounting A
Port 3
Good Frames:
2163304 |######################
CRC Errors:
124456 |##
Alignment Errors:
93342 |#
Runt Frames:
31114 |
Long Frames:
0 |
Bad Frames:
248912 |####
Total Frames:
2412216 |######################
Port Collisions:
0 |
Late Collisions:
0 |
Short Events:
0 |
Jabber Lockups:
0 |
Port Partitions:
0 |
Data Rate Mismatches:
0 |
Source Address Changes:
0 |
------------------------
