AT-S10 Management Software User’s Guide
19
Reconnection
Standard IEEE reconnection algorithm. Entering S for this option
specifies that a
Partitioned port is automatically changed back to
Enabled if this port receives or transmits data without collision for a
period of 512 bit times.
Alternate reconnection algorithm. Entering A for this option specifies
that a
Partitioned port is automatically changed back to Enabled only
if this port receives data without collision for a period of 512 bit times.
Link Test
Link Test On. Entering L for this option enables the module to perform a
10Base-T link pulse test on this port. If the link between this port and a
device is good, the status screen shows the port to be
Online . If the link is
not good, for example, because the device is powered off or there is a break
in the cable, the status shows this port to be
Offline .
Link Test Off. Entering O for this option prevents the module from
performing this test and link state for the port shows as blank (--). The
port could still be online or offline, however.
Polarity
Polarity Correction. Entering P for this option enables the module to
automatically reverse the port’s polarity as appropriate. If the port’s
receive pair polarity is correct, the status shows as
Normal . If the status
shows as Corrected , that means the software has detected incorrect
polarity and has automatically fixed it.
No Polarity Correction. Entering N for this option prevents the module
from reversing polarity automatically; you must manually do so yourself.
The port can still have normal polarity; however, if the status shows
Reversed , that means the software has detected incorrect polarity but
cannot correct it.
Change Port Name
This option allows you to specify a new name for the selected port.
1. Enter C for Change port name to display the following screen:
2. Enter a new name of up to 20 characters for the port, or press Return
to keep the current configuration.
To delete an existing name, press Spacebar twice and press
Return .
The port list is updated with the port’s new name, if you assigned
one.
Zero Counters
This option clears all of the statistics counters for this port to zero.
Sunnyvale
Module 1—Accounting A
Port 1
This port’s current name is:
Null (not currently configured)
Please enter a new name, or Return to retain the existing name:
->
