Management Menus
32
The following example is the SAT when you select D:
The SAT stores up to 300 MAC addresses per module in volatile
memory and displays 20 addresses per page. The table also
displays the ports where the addresses were detected. During the
learning mode, the page number increases as the table is updated
with more MAC addresses until the 300th address is detected (page
15 of the SAT). If any port has not detected a MAC address since
the last power reset, the address entry for that port is blank (---).
MAC addresses aren’t fixed to the ports; the hub relearns a MAC
address if you move a device to another port.
3. Press Return to go back to the previous menu.
To edit the Source Address Table:
You can edit the SAT whether the module is in secure or learning mode.
1. Select one of the following options from the Security/Source
Address Table menu:
❑ Enter B to erase the addresses in the table.
When you erase the table while the module’s learning mode is
enabled, the system enters new addresses as soon as they appear
on the ports. In case of a power failure while the learning mode is
on, MAC addresses in the table are lost. However, once power is
restored, the module quickly relearns addresses as long as the
learning mode is still enabled for that module. In the secure mode,
the SAT is saved and will survive power failures and module resets.
❑ Enter C to add or D to delete a MAC address manually.
When you manually add an address, the system does not enter a
port number until it actually detects the address on one of the
ports.
2. Press Return to leave the SAT screen and go back to the previous menu.
Sunnyvale
Module 5-Engineering
Source Address Table - Page 1
MAC Address Port MAC Address Port
00AA00 5E3DC2 11 0000F4 B1567E 21
00C07B 4D06D3 2 00AA00 5E3710 15
080009 95D13D 10 080020 74A55B 8
080009 2ADA9D 5 080009 9BDB2B 12
080009 2B7489 13 080009 681B97 18
080009 1DFEB5 1 080009 6F5610 4
080009 16BA5A 17 080009 984673 9
080020 739089 3 080020 715907 6
00000C 18E2F3 14 0000F4 E43068 7
00A0D2 000285 16 0000F4 D03D18 20
Please select an option:
Next page
(hit Return to resume the previous menu)
