AT-S10 Management Software User’s Guide
17
Port Status Menu
When you select Port status from the main menu, a menu similar to
the following appears:
This display shows the list of the selected module’s ports, current status,
and configuration. The display shows the MAC address last seen by the
ports. The MAC addresses dynamically change every time the ports detect
new addresses.
The last line represents the appliqué port configured as an attachment
unit interface (AUI). In this example, it is being used as an uplink port;
therefore,
Link and MAC Learning are not applicable. After you have
assigned a name to any port, the name appears after the port number, as
in ports 1 through 4 above.
This display is automatically updated every few seconds when the
management agent is configured for a terminal with cursor control
capabilities (such as ANSI). When using terminals without cursor control,
you can manually update the screen by pressing the space bar.
Sunnyvale
Module 1—Accounting A
Port Status
Port MAC Address Link Status MAC Learning
1: Room 1148 00A0D2 80016E Online Normal Enabled
2: Room 1149 0000F4 C02789 Online Normal Enabled
3: Room 1150 0000F4 D0D070 Online Normal Enabled
4: Room 1151 00805F 84239F Online Normal Enabled
5: 00805F 4810F2 Online Normal Enabled
6: 000094 4514A6 Online Normal Enabled
7: 00805F E49A0B Online Normal Enabled
8: 080009 984673 Online Normal Enabled
9: 0000F4 D09603 Online Normal Enabled
10: 0000F4 C00520 Online Normal Enabled
11: 080020 681B97 Online Normal Enabled
12: 0080C7 68A081 Online Enabled Enabled
13: -- -- Normal Disabled
Enter a port number to change a port’s configuration
- or hit Return to continue with no changes
->
AUI port
