AT-S10 Management Software User’s Guide
45
After this message is broadcast, the management agent switches to
Activity Monitor mode to enable you to monitor download activity. The
screen displays messages similar to the following example:
The numbers 00000 and 99999 are the beginning and ending addresses,
respectively, of the portion of memory currently being downloaded.
Reset to Defaults
This option allows you to clear all your configurations (port names, hub
names, and so on) back to the default, that is, the configurations provided
by Allied Telesyn. When you select
Reset hub config to
manufacturing defaults , the software requires you to confirm.
Activity Monitor
This option displays a variety of messages showing system activity as it
occurs. You enter this mode by selecting either the
Activity Monitor
option from the Administration menu. Network events are displayed as
they occur. To return to the Administration menu, press Return .
The values displayed are for illustration only: your screen may display the
values appropriate for the system you are configuring.
Sample department concentrator reconfiguration messages appear as
follows:
Sample port reconfiguration messages appear as follows:
The port number is replaced with the value AUI when appropriate.
If the master detects the presence of a slave that is not running the same
version of the software, it displays the following message:
Activity Monitor
(hit Return to resume the previous menu)
Download request received from Third Floor Hub
Sending...: 00000 - 99999
Load completed
Sunnyvale
module1 Accounting A is now online.
module2 Accounting B has been removed!
module4 Marketing B has failed!
Sunnyvale
module5, port12: Port is now partitioned.
module3, port8: Port is no longer partitioned.
module3 (Marketing A), port10: Port is now offline.
module3 (Marketing A), port2: Port is now On Line.
Sunnyvale
Updating software in module5
