AT-S10 Management Software User’s Guide
41
Contact String. This parameter is optional. Enter M to display the
following screen:
Enter the SNMP Contact string that identifies the name of the person
within your organization primarily responsible for this hub. You can
include a telephone number if you want. This string is displayed by SNMP
management stations.
Terminal
Configuration
Menu
If you select Terminal configuration from the Administration
menu, the following new menu appears:
You may select several options to specify the characteristics of your
terminal and the serial interface. Default options are highlighted with an
arrow (>).
Omega supports the control codes that adhere to the American Standard
Code for Information Interchange (ASCII) character set, listed in Table 2.
Sunnyvale
‘Contact’ is a string that identifies the person primarily responsible for
this device (someone to contact in case of problems), e.g., “Joe Smith”.
The current Contact string is:
Null (not currently configured)
Please enter a new string, or Return to retain the existing one:
->
Sunnyvale
Please select an option:
ANSI — VT100-compatible
> Generic “dumb” terminal
> 8 data bits
7 data bits
> 1 stop bit
2 stop bits
> No parity
Odd parity
Even parity
> Full duplex (echo)
Half duplex (no echo)
Data rate (“baud” rate)...
->
