AT-S63 Management Software Menus Interface User’s Guide
Section VI: Virtual LANs 689
Displaying MAC Address-based VLANs
To view the details of a MAC address-based VLAN, perform the following
procedure:
1. From the Main Menu, type 2 to select VLAN Configuration.
The VLAN Configuration menu is shown in Figure 199 on page 600.
2. From the VLAN Configuration menu, type 4 to select Show VLANs.
The Show VLANs menu is shown in Figure 234.
Figure 234. Show VLANs Menu with MAC Address-based VLANs
The Show VLANs menu displays a table that contains the following
columns of information:
VID
The VLAN ID.
VLAN Name
Name of the VLAN.
VLAN Type
The VLAN type. The possible settings are:
Allied Telesyn AT-9448T/SP - AT-S63
Marketing
User: Manager 11:20:02 02-Mar-2005
Show VLANs
VID VLAN Name VLAN Type Protocol Member Port(s)
------------------------------------------------------------------
1 Default_VLAN Port Based Untagged
Configured: 20-48
Actual: 20-24
Tagged: 7,9
11 Sales Port Based Untagged
Configured: 1-5
Actual: 1-5
Tagged: 9
15 Engineering MAC Based U:
T:
16 Production MAC Based U:
T:
N - Next Page
U - Update Display
R - Return to Previous Menu
Enter your selection?
