AT-S63 Management Software Web Browser User’s Guide
Section II: Advanced Operations 151
Displaying the Access Control Lists
To display the current ACLs, perform the following procedure:
1. From the Home page, select Monitoring.
2. From the Monitoring menu, select Network Security.
3. Select the ACL tab.
The ACL tab is shown in Figure 48.
Figure 48. ACL Tab (Monitoring)
The ACL tab displays a table of the currently configured ACLs with the
following columns of information:
ID
The ID number for the ACL.
Description
A description of the ACL.
Action
The ACL action of Permit or Deny. An action of Permit means the port
accepts the packets that meet the criteria of the classifiers assigned to
the ACL. An action of Deny means the port discards the packets,
unless the packets also match the criteria of a Permit ACL, in which
case the packets are accepted by the port, because a Permit ACL
overrides a Deny ACL.
Active
Whether or not the ACL is active. A status of Yes means that the ACL
