9.3.6 User Configuration
From menu entry User Configuration it is possible
to administer all users that have access to Pan & Tilt.
Administrator type users can access the product
configuration. Users such as Operators, Users and
Anonymous have limited access to the management
pages.
Fig. 109
The device can be configured only by users
with administration privileges.
9.3.7 Movement Parameters
From menu entry Movement Parameters it is
possible to control, via web, all Pan & Tilt parameters.
• Offset Pan: The pan & tilt has a mechanically
defined 0° position. The Offset Pan function allows
the definition of a different 0° position using
software.
• Fast Mode: It allows moving the Pan & Tilt at high
speed by moving the joystick to the end run.
• Economy Mode: It reduces the motor's torque
when the Pan & Tilt is at standstill to decrease
consumption. Do not enable in the presence of
strong wind or vibrations.
• Ceiling Mount: It rights the image and reverses
the handling controls.
• Autoflip: Turn the Pan & Tilt by 180° when the tilt
of the Pan & Tilt reaches the end run. It makes it
easier tracking subjects along corridors or roads.
• Maximum Speed: Sets the maximum manual
speed.
• Speed With Zoom: Enables the option Speed with
Zoom. When enabled, this parameter automatically
slows down the Pan & Tilt speed, based on the
Zoom factor.
• Tilt factor: Sets the reduction factor of the tilt axis
manual speed.
• Pan Limits: Enables the limits of Pan.
• Pan Start: Sets the start limit of Pan.
• Pan End: Sets the end limit of Pan.
• Tilt Limits: Enables the limits of Tilt.
• Tilt Start: Sets the start limit of Tilt.
• Tilt End: Sets the end limit of Tilt.
Fig. 110
