Range: 1 - 5 = Memory Bucket # (1 – 5) Active
DVC70.AlarmState
Range: 1 – 5 = Alarm State for Memory Bucket 1 – 5
DVC70.PercentUsed
Possible Values: 50%, 60%, 70%, 80%, 90%, 95%, 98%, and 100%
DVC70.MinSec
Bits: bits 0 – 6 (Seconds) – 0 - 59
bits 8 – 15 (Minutes) – 0 - 59
DVC70.DayHours
Bits: bits 0 – 4 (Hours) – 0 - 23
bit 5 PM or AM – 0 or 1
bit 6 12 or 24 hour clock – 0 or 1
bits 8 – 15 (Day of the Week) – 1 - 7
DVC70.MonthDate
Bits: bits 0 – 5 (Date) – 1 - 31
bits 8 – 13 (Month) – 1 - 12
DVC70.Year
Bits: bits 0 – 7 (Year) – 00 - 99
Memory Bucket Name
Range: 1 Name per Memory Bucket
Memory Bucket Name.VarName1 – 10 (Trend only)
Range: 1 Name per Variable
Memory Bucket Name.VarName1 – 5 (Event or Fault) – the application programmer uses this variable to set up
the Message to be displayed if the event becomes true and to set up the Scaling factor
Range: 1 Name per Variable
SF1 – 12
Possible Values: SF1 = 0 = None
SF2 = 4096 = 1:1
SF3 = 8192 = -1 Volt to 1 Volt
SF4 = 12288 = 0 Volts to 5 Volts
SF5 = 16384 = 0 Volts to 10 Volts
SF6 = 20480 = 4 ma to 20ma
SF7 = 24576 = Supply Volts
SF8 = 28672 = True / False
SF9 = 32768 = On / Off
SF10 = 36864 = 0.1
SF11 = 40960 = 0.01 (s)
SF12 = 45056 = 0.001
Memory Bucket Name.Data1 – 5 (Event or Fault)
Range: 1 Data point for each Variable (1 – 5)
