High Country Tek DVC80 - Manual (Page 144)

P/N: 021-00154, Rev. A.6 - updated for V4.7 Tools Page | 144
B3 (+) 5VDC E3
C1 F1 PWR COM
C2 TERM1 F2 PWR COM
C3 TERM2 F3
DVC80
5 Pin J1939 connecter (P15)
Pin Function
1 NC
2 NC
3 NC
4 CAN H
5 CAN L
