P/N: 021-00154, Rev. A.6 - updated for V4.7 Tools Page | 140
C3 DIG IN 4 (SINK) G1 DIG IN 14 (SINK) K2 DIG IN 24 (SINK)
D1 DIG IN 5 (SINK) G2 DIG IN 15 (SINK) K3 DIG IN 25 (SINK)
DVC22
18 Pin Metri-Pak connector (P20)
Pin Function Pin Function
A1 DIG IN 26 (SINK) D1 DIG IN 35 (SINK)
A2 DIG IN 27 (SINK) D2 DIG IN 36 (SINK)
A3 DIG IN 28 (SINK) D3 DIG IN 37 (SINK)
B1 DIG IN 29 (SINK) E1 DIG IN 38 (SINK)
B2 DIG IN 30 (SINK) E2 DIG IN 39 (SINK)
B3 DIG IN 31 (SINK) E3 DIG IN 40 (SINK)
C1 DIG IN 32 (SINK) F1 RXD
C2 DIG IN 33 (SINK) F2 TXD
C3 DIG IN 34 (SINK) F3 SIG COM
DVC22
5 Pin J1939 connecter (P21)
Pin Function
1 NC
2 NC
3 NC
4 CAN H
5 CAN L
** Power and GND are not supplied
to the CAN Bus by the DVC5
10.6 DVC41 Hardware Connections
DVC41
30 Pin Metri-Pak connector (P8)
Pin Function Pin Function Pin Function
A1 HS OUT 1 D2 PWR COM G3 PWR COM
A2 PWR COM D3 PWR COM H1 HS OUT 12
A3 RXD E1 HS OUT 5 H2 PWR COM
B1 HS OUT 2 E2 HS OUT 6 H3 PWR COM
B2 PWR COM E3 HS OUT 7 J1 (+) POWER IN 1
B3 TXD F1 HS OUT 8 J2 (+) POWER IN 2
