MNBLUE Midnight Blue
NAVY Navy
WGRAY Warm Gray
data The Trendchart uses this field as where the new data field to be recorded is located
flag Trendchart uses this field to indicate when a new data point is being transmitted. This
field will alternate between > 0 and 0 (true and false).
h
Specifies the height in pixels of the object.
imageno Bitmap object identifier. Consult HCT for more information on bitmaps.
justify Text justification in the object l (left), c (center) or r (right)
key This field specifies the integer value 0-99 to be returned to the DVC controller application
when the object is touched. 0 implies that the key is inactive and will not be returned
when the object is touched.
lbl
Text inside a button object
lokey Used in Button Array to specify key values returned when touched. Lokey = Button(1,1)
value. Lokey+1 = Button (2,1) value, etc.
min
Lower value of a range for a scale
max Upper value of a range for a scale
pts Used in Trendchart to indicate the number of values to be displayed.
radius Tachometer size
side Scale side l (left) or r (right) with respect to the slider object typically.
size Text size in pixels
state Determines the Checkbox object state. > 0 means checked whereas 0 means blank
t
Specifies the text to be inserted into the object.
t1, ... Specifies the text for each element of a button array. A blank field indicates that this
button is not active or shown
text Use this field to specify the text to be displayed in the object. The Listbox uses a
semicolon to separate lines of text.
txtclr Text color for the text object. Refer to clr field for valid entries.
value
Specifies the value (integer) to be displayed.
w Specifies the width in pixels of the object.
x Specifies the upper left x pixel coordinate of the object.
y Specifies the upper left y pixel coordinate of the object.
