DVC21
18 Pin Metri-Pak connector (P6)
Pin Function Pin Function
A1 DIG IN 26 (SOURCE) D1 DIG IN 35 (SOURCE)
A2 DIG IN 27 (SOURCE) D2 DIG IN 36 (SOURCE)
A3 DIG IN 28 (SOURCE) D3 DIG IN 37 (SOURCE)
B1 DIG IN 29 (SOURCE) E1 DIG IN 38 (SOURCE)
B2 DIG IN 30 (SOURCE) E2 DIG IN 39 (SOURCE)
B3 DIG IN 31 (SOURCE) E3 DIG IN 40 (SOURCE)
C1 DIG IN 32 (SOURCE) F1 RXD
C2 DIG IN 33 (SOURCE) F2 TXD
C3 DIG IN 34 (SOURCE) F3 SIG COM
DVC21
5 Pin J1939 connecter (P7)
Pin Function
1 DRAIN
2 **V+ (NC)
3 **V+ (NC)
4 CAN H
5 CAN L
** Power and GND are not supplied
to the CAN Bus by the DVC5
10.5 DVC22 Hardware Connections
DVC22
30 Pin Metri-Pak connector (P19)
Pin Function Pin Function Pin Function
A1 PWR COM D2 DIG IN 6 (SINK) G3 DIG IN 16 (SINK)
A2 PWR COM D3 DIG IN 7 (SINK) H1 DIG IN 17 (SINK)
A3 PWR COM E1 DIG IN 8 (SINK) H2 DIG IN 18 (SINK)
B1 PWR COM E2 DIG IN 9 (SINK) H3 DIG IN 19 (SINK)
B2 (+) POWER IN E3 DIG IN 10 (SINK) J1 DIG IN 20 (SINK)
B3 DIG IN 1 (SINK) F1 DIG IN 11 (SINK) J2 DIG IN 21 (SINK)
C1 DIG IN 2 (SINK) F2 DIG IN 12 (SINK) J3 DIG IN 22 (SINK)
C2 DIG IN 3 (SINK) F3 DIG IN 13 (SINK) K1 DIG IN 23 (SINK)
