8 Programming Notes
8.1 Examples of Program Statements and Logical Operators
Dim Fault as Uint Declare “Fault” as a variable for use in the project
Dim Timer_0 as Timer Declare “Timer_0” as a count down timer
Dim Scale_Factor as EEmem Declare “Scale_Factor” as a location in EEmemory
Const Low_Limit = 256 Declare the constant “Low_Limit” to equal 256
PWM_1.Enable = True Set PWM_1.enable to True
If (Dig_1 AND Dig_2) Then
PWM_1 = Ana_1 / Scale_Factor If Dig_1 and Dig_2 are true then,
Set the value of PWM_1 to the equation (Analog input 1 divided
by the value stored in the EEmemory location “Scale_Factor”
ElseIf (Dig_1 OR Dig_2) Then
PWM_1 = (Ana_1 / Scale_Factor) / 2 If Dig_1 or Dig_2 are true but not both then,
Set the value of PWM_1 to the Equation (Analog input 1 divided
by the value stored in the EEmemory location “Scale_Factor”
divided by 2)
ElseIf (Dig_3 XOR Dig_4) Then
PWM_1 = ((Ana_1 / Scale_Factor) * 2) If Dig_1 or Dig_2 are true but not both then,Set the value of
PWM_1 to the Equation (Analog input 1 divided by the value
stored in the EEmemory location “Scale_Factor” multiplied by 2)
ElseIf (Dig_1 = NOT Dig_5) Then
PWM_1 = 0x0200 If Dig_1 is not equal to Dig_5 then,
Set the value of PWM_1 to 200hex (or 50%)
Else
PWM_1 = Low_Limit
End If If none of the above statements are true then, Set the value of
PWM to the constant “Low_Limit” End of the IF Statement
If (Uni_1 <= 5.5%) Then
HS1 = True
HS2 = False If Uni_1 is equal to or less than 5.5% then,
High-Side 1 equals True
High-Side 2 equals False
ElseIf (Uni_1 > 5.5% and Uni_1 < 10%) Then
HS1 = False If Uni_1 is greater than 5.5% and less than 10% then,
ElseIf (Uni_1 >= 10.5%) Then
HS1 = True
End If If Uni_1 is equal to or greater than 10.5% Then…
End of If Statement
If (Uni_1 <> 0) Then
HS4 = True
Else
HS4 = False
End If If Uni_1 is not zero then,
High-Side 4 equals True
If Uni_1 is zero then
High-Side 4 equals False
End of If Statement
If (Dig_7) Then
Timer_0 = 2.5s
ElseIf (Dig_8) Then
Timer_0 = 500ms
End If If Dig_7 is True then,
Set Timer_0 to 2.5 seconds
If Dig_8 is True then,
Set Timer_0 to 500 milliseconds
End of If Statement
Fault = (supply >13.8sv) If the Supply Voltage is greater than 13.8 Volts “Fault” equals
True
Dim Timer_0 Timer
If (Timer_0 = 0) Then
Dig_1 = Not (Dig_1)
Timer_0 = 2s
End If
Dim STRname as String “string “
VirtualDisplay.v1 = STRname Toggles a Digital input every time the Timer times out
Defines STRname as string type and assigns “string” to it.
8.2 Variable Display Types
0 to 100%
Scales the displayed value to a percentage of the value in engineering units (0 to 1023) and displays as a whole
number. For example if the variable was displaying the input Ana_1 and the value at the input was 327 in
engineering units (31%) then the displayed value would be 31 (%).
